STD/STS S5M-320 timing belts

STD 320-S5M Timing Belt Replacement 64 Teeth

Model Number:STD S5M-320
Material: Neoprene rubber with fiber glass core
Belt Height: 3.4mm
Tooth Height: 1.91mm
Pitch: 5mm
Tooth nubmer:64 teeth
Width: 6mm ,9mm,10mm ,12mm,15mm ,18mm,25mm,30mm,35mm 40mm.50mm or customized
Customized: Yes

Alternative Part Number(s)/Synchronous Timing Belt Number:

STD-320-S5M-06. STD-320-S5M-09. STD-320-S5M-10.
STD-320-S5M-12. STD-320-S5M-15. STD-320-S5M-18.
STD-320-S5M-20. STD-320-S5M-25. STD-320-S5M-30.
STD-320-S5M-35. STD-320-S5M-40.STD-320-S5M-50
320-S5M STS S5M-320
320-S5M-09.320-S5M-10.320-S5M-12.320-S5M-15.
320-S5M-18.320-S5M-20.320-S5M-25.320-S5M-30.
320-S5M-35.320-S5M-40.100-S5M-320. 320-S5M-50

STD S5M-320 timing belts are rubber timing belts enabling powerful and reliable solutions in a wide range of performances.

About Shipping:

1. Handling Time: Most belts in stock, just cut the length as per your request, so we can ship out within 1-2 working days.

2. We normally ship the packages by UPS, Fedex or DHL and so on
but if you want cheaper shipping, such as China Post , E-Packet, Aliexpress Standard Shipping and so on, welcome contact us.

About Return Policy:

1. If quality problem, we very like to change a new belt for free, or refund to you.

2. If no quality problem, we do not accept refund, Becasue all belts width cut by your request, they are customize, Thank you for understanding
