STD/STS S5M-1165 timing belts

STD S5M-1165 rubber timing belt placement 233 teeth

Model Number:STD S5M-1165
Material: Neoprene rubber with fiber glass core
Belt Height: 3.4mm
Tooth Height: 1.91mm
Pitch: 5mm
Tooth nubmer:233 teeth
Width: 6mm ,9mm,10mm ,12mm,15mm ,18mm,25mm,30mm,35mm 40mm.50mm or customized
Customized: Yes
Package: 1pcs STD S5M-1165 Timing Belt Replacement 233 Teeth
Useage field:
The STD profile S5M timing belts are used in all industrial applications for compact drives in small home appliances, printers, scanners, copiers, textile machines, machine tools and many other machines and equipment

Alternative Part Number(s)/Synchronous Timing Belt Number:

STD-1165-S5M-06. STD-1165-S5M-09. STD-1165-S5M-10.
STD-1165-S5M-12. STD-1165-S5M-15. STD-1165-S5M-18.
STD-1165-S5M-20. STD-1165-S5M-25. STD-1165-S5M-30.
STD-1165-S5M-35. STD-1165-S5M-40.

1165-S5M STS S5M-1165

1165-S5M-09.1165-S5M-10.1165-S5M-12.1165-S5M-15.
1165-S5M-18.1165-S5M-20.1165-S5M-25.1165-S5M-30.
1165-S5M-35.1165-S5M-40.100-S5M-1165
